How freeze-drying works?
Freeze drying works by first freezing a substance, then lowering the pressure around it to a vacuum, which allows the frozen water to directly transition from a solid (ice) to a gas (water vapor) through a process called sublimation, effectively removing the water content without going through a liquid phase, thus preserving the material's structure and properties; this is often used to preserve food, pharmaceuticals, and biological samples by significantly extending their shelf life.
For what purpose is this freeze-dried food intended?
Outdoor adventure: freeze-dried instant soup, freeze-dried meat
Baby food: freeze-dried fruit powder, freeze-dried vegetable granules
Catering: freeze-dried spices, freeze-dried decorative flowers
Military emergency: freeze-dried staple food, freeze-dried protein
Health products: freeze-dried Ganoderma lucidum powder, freeze-dried enzyme
The technical data of Model A series- 25㎡ vacuum freeze dryer
| Model No. | A25 |
| Nominal total loading areas(㎡) | 25 |
| Loading capacity of raw material(kg/batch) | 330 |
| Manner of heating | Radiant heating from two sides of the heating plate |
| Heating temperature ranges(℃) | From room temperature to 120 |
| Nominal min. working pressure(Pa) | 30~120 |
| Max.capacity of vapor condenser(Kg/h) | 57.5 |
| Evacuation time to reach within 133Pa(min.) | 15~20 |
| Required cooling capacity(-40℃)（kw） | 45 |
| Max.vapor consumption(Mpa)(kg/h) | 70 |
| Total power consumption of the whole systems(kw) | 30 |
Company profile
Dalian Iceberg Freeze Drying Technology Co., Ltd. is a premier manufacturer specializing in Industry freeze dryer and Individual Quick Freezing (IQF) equipment. As an integrated leader in R&D, production, and we combine cutting-edge technology with global expertise to deliver:
✅ High-efficiency Industry freeze dryer & IQF systems
✅ Low operational costs with energy-optimized designs of Industry freeze dryer
✅ Fast project execution for seamless global deployment of Industry freeze dryer
✅ 30+experience in Industry freeze dryer
✅ Industry freeze dryer Approved for export to the EU and Japan."
Delivery for 25㎡ vacuum freeze dryer
FAQ
What does the completed 25㎡ vacuum freeze dryer include?
✔ Main Processing Units of 25㎡ vacuum freeze dryer
Drying chambers with integrated thermal systems
✔ Critical Subsystems of 25㎡ vacuum freeze dryer
Vacuum systems
Refrigeration system
✔ Operational Infrastructure of 25㎡ vacuum freeze dryer
Industrial control center
✔ Material Flow Components of 25㎡ vacuum freeze dryer
Anodized-trays & trolleys
Corrosion-resistant rail system
Retains nutrients: Freeze-dried food retains up to 97% of its nutrients, including vitamins, minerals, and antioxidants. Long shelf life: Freeze-drying removes the potential for bacterial growth, so freeze-dried food can last for years. Maintains flavor and texture: Freeze-drying preserves the original shape, flavor, and texture of food. Sustainable: Freeze-drying reduces food waste and transportation and storage costs.
Freeze drying works by first freezing a substance, then lowering the pressure around it to a vacuum, which allows the frozen water to directly transition from a solid (ice) to a gas (water vapor) through a process called sublimation, effectively removing the water content without going through a liquid phase, thus preserving the material's structure and properties; this is often used to preserve food, pharmaceuticals, and biological samples by significantly extending their shelf life.
We Dalian Iceberg produce and supply freeze drying equipment with the below types and sizes: 1)Type: Industrial scale of freeze dryers with internal assembly of vapor trap(s) with separate condensers performing the functions of alternative vapour trapping and de-icing Sizes: A50, A75, A100, A125 and A200 2)Type: Pilot Freeze-dryers with one-time condenser Size: A5, A10, A20, A30 We can also develop other model of pilot freeze-dryers according to customer’s demands
It is 120-150 days in Europe and the United States, and 90-120 days in other regions.
Within 24 hours
The following 14 items of supplies are included in the contract price offer: 1) Drying chambers (with already integrated internal packages of the heating plates and the condensers) 2). Hot water system 3). Vacuum system with units for initial evacuation and vacuum maintaining 4). Ammonia circulation system 5). Alternative de-icing system 6). Pneumatic system 7). Cooling system (cooling tower) 8). Control centre with control panels and computer 9). Freezing tunnels 10). Rail system 11). Trolleys 12). Trays 13). Connecting pipes, pipe fittings and valves for systems 14). Cables, wires, shielded control lines, etc. for all systems We can also add other equipment according to customer's request.
