Food and beverage freeze dryer
Where is this freeze-dried food for?
-Outdoor adventure: freeze-dried instant soup, freeze-dried meat
- Baby food: freeze-dried fruit powder, freeze-dried vegetable granules
-Catering: freeze-dried spices, freeze-dried decorative flowers
-Military emergency: freeze-dried staple food, freeze-dried protein
-Health products: freeze-dried Ganoderma lucidum powder, freeze-dried enzyme
The technical data of Food and beverage freeze dryer(Combination type)
| Combination type for industrialized product | ||||||
| Model | 2XA25 | 2XA50 | 2XA75 | 2XA100 | 2XA125 | 2XA200 |
| Loading capacity (kgs/batch) | 660 | 1320 | 1980 | 2640 | 3300 | 5280 |
| Nominal total loading area of heating plates(㎡) | 50 | 100 | 150 | 200 | 250 | 400 |
| Max.capacity of vapor condensing (kg/h) | 115 | 230 | 350 | 460 | 560 | 900 |
| Operating temperature of heating plates (℃) | 30~120 | 30~120 | 30~120 | 30~120 | 30~120 | 30~120 |
| Nominal working pressure (Pa) | 30~120 | 30~120 | 30~120 | 30~120 | 30~120 | 30~120 |
| Evacuating time to reach within 133 Pa with empty loading (min.) | 15~20 | |||||
| Required peak cooling capacity at -40℃(kw) | 80 | 158 | 240 | 320 | 360 | 650 |
| Max.vapor consumption of 0.7 MPa (kg/h) | 120 | 220 | 360 | 480 | 700 | 1150 |
| Installation power (KW) | 50 | 89 | 90 | 115 | 115 | 165 |
Supply scope of comprehensive freeze-drying system of Industries batch freeze drying machine
| System Component | Key Features |
| Drying Chambers | Pre-integrated heating plates & condensers |
| Thermal Systems | Hot water system + ammonia circulation |
| Vacuum Systems | Dual-stage evacuation with maintenance pumps |
| Material Handling | Freezing tunnels, rail system, trolleys & trays |
| Control Infrastructure | Centralized control center with industrial PC and HMI panels |
| Ancillary Systems | Complete piping, valves, electrical cabling, and pneumatic systems |
Customizable configurations available upon request | |
A sample plant of Food and beverage freeze dryer
Company profile
Dalian Iceberg Freeze Drying Technology Co., Ltd. is a leading manufacturer of Food and beverage freeze dryer and individual quick freezing (IQF) equipment, integrating R&D, production, and engineering services. Our technology, optimized with global expertise, delivers high efficiency, low operational costs, and rapid project execution—trusted by clients across China and internationally, including Japan.
"Quality Driven, Integrity Rooted." We partner with industries worldwide to pioneer sustainable freezing solutions.
CE Certification of Industries batch freeze drying machine
FAQ
What is the complete freeze drying of Industries batch freeze drying machine solution includes?
✔ Main Processing Units
Drying chambers with integrated thermal systems
Alternative de-icing for maximum uptime
✔ Critical Subsystems
Vacuum systems (evacuation + maintenance)
Closed-loop ammonia refrigeration
✔ Operational Infrastructure
Industrial control center (CE-certified)
✔ Material Flow Components
Anodized-trays & trolleys
Corrosion-resistant rail system
Retains nutrients: Freeze-dried food retains up to 97% of its nutrients, including vitamins, minerals, and antioxidants. Long shelf life: Freeze-drying removes the potential for bacterial growth, so freeze-dried food can last for years. Maintains flavor and texture: Freeze-drying preserves the original shape, flavor, and texture of food. Sustainable: Freeze-drying reduces food waste and transportation and storage costs.
Freeze drying works by first freezing a substance, then lowering the pressure around it to a vacuum, which allows the frozen water to directly transition from a solid (ice) to a gas (water vapor) through a process called sublimation, effectively removing the water content without going through a liquid phase, thus preserving the material's structure and properties; this is often used to preserve food, pharmaceuticals, and biological samples by significantly extending their shelf life.
We Dalian Iceberg produce and supply freeze drying equipment with the below types and sizes: 1)Type: Industrial scale of freeze dryers with internal assembly of vapor trap(s) with separate condensers performing the functions of alternative vapour trapping and de-icing Sizes: A50, A75, A100, A125 and A200 2)Type: Pilot Freeze-dryers with one-time condenser Size: A5, A10, A20, A30 We can also develop other model of pilot freeze-dryers according to customer’s demands
It is 120-150 days in Europe and the United States, and 90-120 days in other regions.
Within 24 hours
The following 14 items of supplies are included in the contract price offer: 1) Drying chambers (with already integrated internal packages of the heating plates and the condensers) 2). Hot water system 3). Vacuum system with units for initial evacuation and vacuum maintaining 4). Ammonia circulation system 5). Alternative de-icing system 6). Pneumatic system 7). Cooling system (cooling tower) 8). Control centre with control panels and computer 9). Freezing tunnels 10). Rail system 11). Trolleys 12). Trays 13). Connecting pipes, pipe fittings and valves for systems 14). Cables, wires, shielded control lines, etc. for all systems We can also add other equipment according to customer's request.
